The ST128HDMI2 8-Port High-Speed HDMI® Splitter (rack-mountable) lets you share a single HDMI audio-video source with up to 8 HDMI or DVI-D displays without sacrificing image or sound quality.
Supporting True HD 1080p video resolutions, the HDMI splitter acts as a distribution amplifier that enables you to situate your HDMI-capable displays up to 15ft (5m) away from the splitter, and features 3.5mm audio connections, giving you the option of sending your accompanying audio signal through the HDMI cable, or through a separate channel.
A perfect addition to virtually any application requiring high-quality video, the ST128HDMI2 HDMI splitter is easy to install as a standalone or rack-mounted device using the included brackets and provides flawless, distortion-free digital video.
This product is TAA compliant. High Speed HDMI® support ensures compatibility with the latest HDMI source devices and displays. Signal amplification provides high-resolution HDMI signals without signal degradation/loss of quality
Applications
- Connect HDMI enabled projectors, monitors, plasma screens, commercial billboards, and wall display systems
- Display information in waiting rooms or to patients in healthcare facilities
- Ideal for business conference rooms and trade show displays
- Perfect for classrooms and business multimedia presentations
- Great for digital signage applications displaying video advertisements with audio in retail environments
- Financial applications include stock tickers or promotion of new products/services
Specifications:
1 - Connector A: 3.5 mm Mini-Jack (3 Position); HDMI (19 pin)
8 - Connector B: 3.5 mm Mini-Jack (3 Position); HDMI (19 pin)
Ports: 8
AV Input: HDMI
AV Output: HDMI
Cabling: HDMI
Audio: Yes
Rack-Mountable: Yes
Industry Standards: High-Speed HDMI, HDCP, EDID
Daisy-Chain: Yes
4 - LED Indicators: Green Port signal indicator
1 - LED Indicators: Power (Green) / Input Signal (Blue)
Maximum Cable Length: 5000 mm [196.9 in]
Maximum Digital Resolutions: HDTV 1080p / PC 1920x1200
Supported Resolutions: 1080p (1920 x 1080) / VGA (640 x 480) / SXGA (1280 x 1024) / UXGA (1600 x 1200) / WUXGA (1920 x 1200)
Wide Screen Supported: Yes
Weight of Product: 2.2 kg [4.9 lb]
Colour: Black
Material: Steel
Product Length: 48.0 cm [18.9 in]
Product Width: 18.0 cm [7.1 in]
Product Height: 4.2 cm [1.7 in]
Power Source: AC Adapter Included
Input Voltage: 100 - 240 AC
Input Current: 800mA
Output Voltage: 12V DC
Output Current: 1.5A
Center Tip Polarity: Positive
Plug Type: M
Power Consumption (In Watts): 10.2
What's in the Box: HDMI distribution amplifier; Mounting hardware and screw kit; Universal power adapter (NA / EU / UK / AU); Instruction manual
