The Torq TQUPS700 is a Line Interactive UPS with an LCD display, the newest technology and a powerful function. This TQUPS700 Line Interactive UPS is designed with 2-Steps Boost and 1-Step Buck AVR to stabilize input voltage. The input voltage range is -30% +25%, but output regulation is +/-10%.
The Line Interactive UPS provides you with the ability of perfect protection for your critical devices, which is suitable for computers and electronic equipment with a substantial rectifier or capacitive loads. This UPS is not suitable for electronic equipment with significant inductive loads, such as motors and fluorescent lamps.
Features:
- Line interactive design
- Microprocessor control guarantees high reliability
- Frequency 50/60Hz auto-sensing
- Equipped with 2-Steps Boost and 1-Step Buck AVR to stabilize utility voltage
- Built-in DC start function enables UPS to be started up without AC power supplied
- UPS Green Mode (Energy Saving Function)
- Off-mode charging
- Modem/Phone line surge protection
- Over/Low Voltage, Short-Circuit, and Lightning/Surge(optional) Protection
- Built-in CCCV (Constant Current, Constant Voltage) battery charger
Specifications:
- Model: TQUPS700
- Capacity: 700VA/420W
- Input: 220/ 230/ 240Vac, -30% +25%, 50-60Hz Auto-sensing
- Output: Battery Mode +/-10%, 50-60Hz +/-1Hz
- Battery: 12VDC
- Recharge Time: 5Hrs to 90% after complete discharge
- Battery Protection: Over-Discharge Protection
- Advanced Battery Management: Yes
- Display: LCD Display (Multi-Data)
- Alarm: Buzzer on for Backup mode, battery low, overload
- Output Short Protection: AC fuse and Electronic circuit (Line mode); Electronic circuit (Back-up mode)
- AVR (Automatic Voltage Regulation): Yes
- DC Start Function: Yes
- Over/Under Voltage Protection: Yes
- Dimensions: 305x98x170mm
Rear Panel:
-
AC Input - Connect to input power cord
-
AC Fuse/ Circuit Breaker
-
Outlets
-
RJ-45 or RJ-11 (optional)
-
Communication interface: USB port
